V&F Serves a Broad Range of Attractive & Rapidly Growing End Markets

V&F Serves a Broad Range of Attractive & Rapidly Growing End Markets
    Mission Critical Applications and Equipment
  • Inverters
  • Mobile DC to AC
  • Hi frequency apps
  • Utilities & Municipalities
  • Smart Grid
  • Solar & Wind Power
Critical Power Systems (Facility)
Mission Critical Applications and Equipment
  • UPS’s
  • PDU’s
  • ISP’s
  • Load Banks
  • Data Centers
  • Medical Centers
  • Building Environmental Sys
  • Municipal Bldgs
Industrial Equipment & Controls
Mission Critical Applications and Equipment
  • Power Supplies & Regulators
  • Surge Suppressors
  • Electric Vehicle Battery
  • Chargers Machine Tools
  • Foodservice Equipment
Industrial Motion Control (Drives)
Mission Critical Applications and Equipment
  • Industrial Drives Variable Speed Drives
  • Electric Motors Industrial
  • Automation & Robotics
  • Heavy Industry

V&F Products Span the Spectrum of Critical Power Systems

3 Phase Transformers

  • Grid to Facility
  • Higher voltages

Reactive Magnetics

Reactive versions of 3-Phase and Single-Phase transformers

Single Phase Transformers

Facility power to equipment Medium voltages

Assemblies

    Basic to Complex:
  • Fully enclosed
  • Thermal mgmt.
  • Power mgmt.

Toroids

For non-standard core shapes



Low Power Transformers

Used in devices or controls



V&F Products Span the Spectrum of Critical Power Systems

Power Conversion (Voltage, Frequency)
V&F Product Types and Size Ranges Transformers
  • 3-Phase: 1 kVA thru 5 MVA
  • Single Phase: 40VA thru 150 kVA
  • Toroids: Up to 18 in. OD
  • Low Pwr: 5 mm EE to 11 in. EI (Pwdr Iron)
  • Sensing & Monitoring
    V&F Product Types and Size Ranges
  • Indus./Commerc.
  • Circuit Transformers (CT’s)
  • Toroids: 4.5 in. OD
  • Low Pwr : 6 mm OD thru 4.5 in. OD
  • Attenuating & Filtering (Harmonics)
    V&F Product Types and Size Ranges
  • AC Reactors
  • DC Chokes
  • Pulse Drive Xfrmrs.
  • 3-Phase: 750 KVAR (5000 Lbs)
  • Single Phase: 2350 kVAR (4250 Lbs)
  • Low Pwr: 1500 μH (22 Lbs)
  • System Protection (Short Circuits, Surges)
  • UPS
  • Shielding
  • Isolation Magnetics
  • 3-Phase: 1.25MVA
  • Single Phase: 40VA to 150 kVA
  • Toroids: 3 in. OD to 18 in. OD
  • Low Pwr: 40VA to 15 kVA
  • Component Functionality
  • Reactive Magnetics
  • Specialty Xfrmrs.
  • 3-Phase: 5 MVA (18-36 Pulse)
  • Single Phase: 150 kVA (EPS – Unique Load Profile)
  • Low Pwr: 5mm EE to 6 in. (Powdered Iron)
